Textile Non Woven Jeans 8P Rag Cutting Machine For Soft Material

Brand Name:	Joful
Model Number:	JF 500/800/1200/1600/2400/3200
MOQ:	1 set
Price:	Discussable
Payment Terms:	T/T, L/C
Supply Ability:	Montly 60 sets

Detail Information

Product Description

Detail Information

Place of Origin:

China (Mainland)

Certification:

CE/UL

Product Name:

Fabric Textile Cutting Shredder Rotary Blades

RD:

Customizable Available

QC:

100% Fully Inspection

Blades Design:

Rotary Twisted Blades

Cutting Power:

8P Cutting Motor, Customized Power

Blades Materials:

Alloy Tool Steel

Machine Materials:

Carbon Steel

Machine Colot:

As Your Request

Packaging Details:

Wooden box safety package delivery

Supply Ability:

Montly 60 sets

Highlight:

8P non woven crusher

8P Rag crusher

Product Description

Fabric/Non Woven Cutting Shredder Rotary Blades Power Saving With Sharpener Device Easy Maintenance

Efficiency & Low Power Consumption & Easy Maintenance

Joful J series cutting machine is desined especially for almost all kinds soft type materials, with annual more than 700 sets finished machine export to all over the world
We have already apply patent for our design, we are the only supply in China supply such machine
Different from regular single/double/four shaft shredder in the market, Joful J series cutting machine working principle is to cut the materials with its sharp blades, not to tear up the waste, so it's much power saving compare and cost saving
Adopt with rotating twisted knife design, with application of international leading oblique knob scroll meet the shear design of point moving knife and fixed knife, continuous high-speed shear, just like a big scissors
We equipped every set finish machine with automatic sharpening device, just sharpening the blades according t our suggestions will be ok, on other special tips needed, very easy for maintenance, and the cutting blades can be replaceable, ensure the machine long lifespan

Blades and sharpening device samples

Description About The Textile Fabric Cutting Machine

Machine Components

Normally four parts: Main machine, Input bilt, Output belt, Blades sharpening device, Customized mesh screen

Can also add other parts per client's request, such like: Dusty removal device, Fan device, Metal detector, Opener machine device, sorting machine, spare blades etc

Main Datas

cutting motor	8P motor, 5.5/7.5/15/18.5/22/44/66KW
transport motor	4P Inverter motor, adjustable speed
blades lifespan	generally 12-24 months
blades materials	alloy tool steel
machine materials	carbon teel
power distribution cabinet	independent distribution cabinet
moving knife	Alloy tool steel,4/6/8 pieces knife
fix knife	Alloy tool steel,2 pieces knife
conveyor width	330/520/720/1100mm, effective width
conveyor length	1400/3000/4000mm, or as your request
machine design	rotary twisted knife
machine maintenance	with sharpening device
machine color	yellow, orange, red, blue, milk, customizable

Application

Materials that can cut&crush ( almost including all soft materials)		Discharge size range	Capacity range
Bags / plastic films / strips	Jumbo bags / PP bags / woven & non-woven bags / plastic bags (PP PE PVC ect.. as long as they are soft bags) plastic films	From few Millimeter up to tens centimeter long	from several hundred / hr up to several thousand / hour depends on discharge size request
Textile scraps	quilting edges ,threads, yarns.. Clothes (Underwear scrap,jeans,towel,cap scraps,non-woven fabrics,cotton fabrics ..) Shoes Scraps etc..
Fibers	glass fiber, fiber yarn, Coconut fiber,Polypropylene fiber ,polyester fiber, Silk fiber .. etc..
Foams	Sponge/mattress scraps /flexible PU foam / EPS foam / XPS foam /Rock wool foam / glass wool foam / EPE foam / Cotton , silk cotton etc..
Leather /Carpet / Papers / books /cardboard / plant straw / fish net / ropes etc
