D2 Blade Single Shaft Shredder For Plastic Lumps PP PE PVC PS 22KW Motor

Place of Origin China
Brand Name Joful Industry
Certification CE
Model Number XR600
Minimum Order Quantity 1
Price USD12000-15500
Packaging Details EPE foam & PVC film wrapping packing / export wooden box packing
Delivery Time 15-45 working days
Payment Terms T/T
Supply Ability 150 sets / Year

Contact me for free samples and coupons.

WhatsApp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

Product Details
Shredding Room 600*600 Mm Rotor Diameter 280 Mm
PLC Control Siemens Motor Brand Simo, Wannan, Siemens, Weg
Bearing Heavy Duty Bearing Blade Materials D2, DC53
Hydraulic Station 2.2kw Voltage According To Customer
Main Eletrical Equipment Schneiders Rotary 80 Rpm
Transport Package Stretch Film/Wooden Pallet Output 300-600kg/Hr
High Light

Plastic Lumps Single Shaft Shredder


22KW Motor Single Shaft Shredder


PLC Control Single Shaft Shredder

Leave a Message
Product Description
XR 600 Single Shaft Shredder For Plastic Lumps PP PE,PVC,PS 22KW Motor D2 Blade Material
XR Series single shaft shredder machine

Feature & Function:

  • 1. Single shaft shredder has characters as follows: single shaft shredder properties as follows: strong, durable. It is suitable to recycle a variety of bulk solid materials, refractory materials, plastic containers and plastic barrels, plastic films, fibers, paper. Shredded particles can be small to 20mm according to different needs. We can provide all kinds of feed hopper; low speed rotary cutter in accordance with customer needs , which will be low noisy and energy saving.
  • 2. Single shaft shredder consists of a knife disc and a static knife to complete shredding material. Cutter is composed of a base shaft and several shape quadrilateral knife block. The knife block has 4 blades, can be replacing the use of. The knife block along the axis of the base is in multiple rows into type V, and fixed with screws in the radical axis, rotated with the based shaft together, finally comprise a knife disc. The two static knife is fixed on the machine frame. The material is sent to the cutter by the horizontal hydraulic cylinder. The speed is stable and adjustable, and the propulsive force is large and uniform. It is applicable to the recovery of a variety of bulk solid materials, refractory materials, irregular plastic containers and plastic barrels, tubes, films, fibers, paper etc. Spindle speed is 45 ~ 100 rpm/min.
  • 3. We can offer a variety of rotor configurations to suit different applications.Such as:High Performance Rotor,Hard Material Rotor and Soft and Film Rotor.
  • 4. When customers choose the rotor, we can also offer different knives holder to suit different requirement. Such as:Welded Knife holders,Assembled Knife holders and CNC cutting knife holders.


Application Area:
The single-shaft shredder is used to recycle plastic, paper, wood, fiber, cable, rubber, home appliance, light steel, municipal solid waste, etc. It is ideally suited for the reduction of a wide range of different materials:

Refuse-derived fuel: straw, municipal solid waste;
Textile: cloth fiber, nylon;
Paper: industrial waste paper, packing paper, cardboard paper;
Cable wires: copper core cable, aluminum cable, composite cables;
Polypropylene pipe, industrial packaging & plastic films, PP woven bags;
Plastic: plastic block, plastic sheets, PET bottle, plastics pipe, plastic container, plastic drums;



Technical parameters:


Motor (kw)

Diameter of rotor


Rotating Knife (pcs)

Fixed Knife (pcs)

Hydraulic Motor power (kw)

Weight (kg)
XR600 22 Φ280 75 26+4 2 2.2 2300
