PP PE PVC Films Bags 8P Plastic Waste Shredder Blades Length 1200mm

Joful J series cutting shredder machine is design mainly for soft type materials recycling cutting, we already apply design patent for it, we are the only manufacture in China supply such kind crusher machine

Widely Application

The machine can be used for almost all kinds soft and flexibility type materials cutting, such as below

* Textile scraps: Non-woven fabric, cloth, car interior, yarns, yarns, wool, clothing (underwear scraps, jeans, towel, cap scraps, cotton fabrics)

* Plastic bags / films / strips: jumbo bags, PP bags, woven and non-woven bags, plastic bags (PP PE PVC, etc. as long as they are soft bags), plastic films, PP strips

* Fibers, foams: fiberglass, fiber yarn, coconut fiber, polypropylene fiber, polyester fiber, silk fiber etc

* Leather / Carpet / Airbag cloth pieces / Papers / books / cardboard / vegetable straw / Crop straw / fishing net / raffia / fishing ropes etc.

Large Capacity

The machine adopt twisted rotary blades, maximum blades length 1200mm, 8 pcs rotary blades, 2 pcs stationary blades, 300 rpm, means around 4800 times cutting per minute, the input speed can be adjustable, hourly capacity up to 8000KG

Working Principles

The working principles of the machine is like a scissors, twisted rotary blade design, high-speed rotary cutting, make the cutter machine more efficient and energy-saving, the discharge port is designed with removable sieve mesh, the size of mesh can be customized as your final size request, totally meet your different and uniform discharge size request

Maintenance Tips

* Sharpening the knifes according to our suggestion
* Place the machine on a open and flat ground, avoid tilting
* Pleas running the empty machine for more than 30 minutes, to check if every parts running well
* Avoid metal and other solid materials, that may damage the cutting blad

We have different models cutting machine with different size, blades length and capacity available, each model can be also customized according to your different materials and cutting request

The machine can also add dusty removal device, opening device and sorting device according to your request

Delivery

Machine delivery in wooden box, inner metal frame fixed, outside plywood cover, ensure long distance transportation safety

Installation

* Complete machine delivery, you just need connect the power cord and install the conveyor belt will be ok, we offer you drawings and videos instruction, client can finish the installation easily by themself

* We also support oversea machine install service and training your staffs if you needed

After Sales Support

* 12 months guarantee after the machine arrived, lifelong technology support for free

* Solve all after sale question inquiry within 12 hours ( we can offer instant service if we're in same time zone)
