Woven Bag Single Shaft Shredder 380 V / 50 Hz Low Energy Consumption

Good quality Solid Waste Shredder for sales
Good quality Solid Waste Shredder for sales
Machines running good. Fantastic autually Thank you so much for your help and supporting

—— Mr. Endrit

Machine running ok. and we are very satisfied with after-sale service.

—— Mr. Paulo Duarte

Machine good. Just I hope the return visit can be every month instead of every two weeks 'cause we have no problem ask

—— Mr. Cersor

I'm Online Chat Now

Woven Bag Single Shaft Shredder 380 V / 50 Hz Low Energy Consumption

China Woven Bag Single Shaft Shredder 380 V / 50 Hz Low Energy Consumption supplier

Large Image :  Woven Bag Single Shaft Shredder 380 V / 50 Hz Low Energy Consumption

Product Details:

Place of Origin: CN
Brand Name: Joful
Certification: CE
Model Number: S-600/700/800/1000/1200/1500...

Payment & Shipping Terms:

Minimum Order Quantity: 1 set
Price: Negotiable
Packaging Details: Film , EPE Foam , Export Wooden Box / or per clients request
Delivery Time: 7-48 working days
Contact Now
Detailed Product Description
Product Name: Single Shaft Shredder,woven Bags Shredder , Shredding Machine For Woven Bags Bale ,packed Woven Bags Shredding Machine Suitable: Plastic Lump,die Materials,thick Plastic,thick Rubber,Baled PET Bottles ,aluminum Cans Bale , Film Bale, Paper Bale, Cardboard Bale,woven/jumbo Bags Bale...
Blade Material: SKD-11, D2, DC53, LD, Cr12MoV / Customizable Capacity: Customizable
Motor: 37 Kw / Depends On Shred Demand Installation: Offer Assembly Drawing/video ,support Abroad Installation
Voltage: 380 V / 50 Hz /3 Phase , Customizable Advantage: 100% Inspection Before Delivery And Guarantee Quality



Single Shaft Shredder For Plastic Film Bale , Plastic Film Bale Shredder For Sale ,PET bottles bale shredder





Joful Single shaft woven bags bale shredder consists of moving cutter and stationary knife work together to complete shredding demand. Cutter is consisit by base rotor and quadrilateral shape moving knife blocks. Moving knife block has 4 cutting edges, they are replacing use. Moving knife blocks are arranged in multiple" V-Shape" rows along the base rotor and fixed via screws on the base rotor, rotating together with the base rotor, the two together we call it moving cutter. There are two groups of stationary knife, fixed in the rack. The material is pushed by the horizontal hydraulic cylinder to cutter direction. The speed is smooth and adjustable,propulsion is large and uniform .



Besides the single shaft design shredder, we also many many other design woven bags shredder / crusher. The machine design / size and configurations are different towards to different crushing demand.





Brief Introduction of Single Shaft For Plastic Film Bale


Woven bags bale shredding samples display ( different sizes are availble)



Woven Bag Single Shaft Shredder 380 V / 50 Hz Low Energy Consumption



Main Features of Single Shaft Shredder For woven bags bale / Jumbo bags bale / non-woven bags bale / pvc bags


1. Rugged Mechanical Design,Hardened steel knives and gears ,The blade base and blade on the rotary roller can be dis-assembly .it is easy to clean and maintenance.
2. working in automatically condition,it equiped with hydralic pushing system ,The speed is smooth and adjustable,propulsion is large and uniform .
3. With many sizes of screen available for choosing,so different final sizes are available
4. Single shaft shredder is strong and durable. Suitable for recycling a variety of bulk solid materials
5. Different cutters seaters design for meeting different crushing demands , The rotary blade adopt the V design, It can decrease the noise and decrease energy consumption.





Before we could recommend you suitable machine, we need to learn below information from you first

1. Which Material you need to crush? What's the max size if the materials ? (Better show us clear photos)
2. What's your output demand per hr / day ?
3. What's your final size request ?





Quick details


1. Lead time - 48 working days
2. Payment Term - 30% advanced payment once upon signing the contract,70% balance payment before delivery.
3. Machine Installation

  • a. Almost whole set machine delivery out, very simple for clients to install by themselves and we also offer installation drawing
  • b. If necessary we also support abroad installation

4. Our guarantee period is 12 months. Within the guarantee period the broken parts (excluding quick-wear parts) can be exchanged with our new parts if it is not caused by human factors. And technicians are available for solving big problems overseas(this situation never happened ). Beyond the guarantee period the broken parts dispatched are charged at cost price.
